Electrical plans, in addition to their own information, also need to be dimensioned, which can be a nightmare. However, with careful planning, it’s possible to define the position of each element without filling the drawing with dimensions—and even better, without the need to create elevation plans to show the arrangement of fixtures and switches on the walls.
